Mechanical life: 30,000 cycles min
Electrical life: 10,000 cycles min
Contact Rating: 0.3Amps @30 VDC
Insulation Resistance: >100MΩ DC250V
Withstand Voltage: AC250V 1 minute
Contact Resistance: <50mΩ
Ambient Humidity: <85%RH
Operating Temper.: -25℃ to 70℃
Operating Force: 200±150gf
Soldering process: Hand Soldering:Use a soldering iron of 30 watts,controlled at 380℃ approximately 3 seconds while applying solder
