Contact Rating: 50 mA @ 30VDC;
Electrical life: 3,000,000 cycles
Mechanical life: 3,000,000 cycles min;
Insulation Resistance: >100MΩ DC250V;
Withstand Voltage: AC600V 1 minute;
Contact Resistance: <100mΩ;
Ambient Temper.: -25℃ to 70℃;
Operating Force: 70±20 gf
Soldering Process: Hand soldering,Use a soldering iron of 30 watts,controlled at 380℃ approximately 3 seconds while applying solder. |
