Mechanical life：500,000 cycles min
Electrical life：300,000 cycles min
Contact Rating： 0.2Amps @60 VDC
Insulation Resistance：＞ 100M Ω DC500V
Withstand Voltage： AC500V 1 minute
Contact Resistance：＜ 100m Ω
Ambient Humidity：＜ 85%RH
Operating Temper.： -25 ℃ to 65 ℃
Operating Force ： 200gf
Soldering process：Hand Soldering ： Use a soldering iron of 30 watts ， controlled at 380 ℃ approximately 3 seconds while applying solder 。
|
